SB3003CH-TL-W
onsemi
onsemi
DIODE SCHOTTKY 30V 3A 6CPH
$0.65
Available to order
Reference Price (USD)
3,000+
$0.21003
6,000+
$0.19648
15,000+
$0.18970
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Optimize your electronic designs with the SB3003CH-TL-W single rectifier diode from onsemi. This diode, part of the Discrete Semiconductor Products family, offers exceptional rectification efficiency and thermal stability. Its compact design and high current capacity make it suitable for space-constrained applications like mobile devices, laptops, and IoT gadgets. The SB3003CH-TL-W is also ideal for automotive electronics, including alternators and voltage regulators, where reliability is critical. onsemi's commitment to innovation ensures that the SB3003CH-TL-W meets the highest industry standards for performance and longevity.
Specifications
- Product Status: Obsolete
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 30 V
- Current - Average Rectified (Io): 3A
- Voltage - Forward (Vf) (Max) @ If: 520 mV @ 3 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 20 ns
- Current - Reverse Leakage @ Vr: 42 µA @ 15 V
- Capacitance @ Vr, F: 90pF @ 10V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: SOT-23-6
- Supplier Device Package: 6-CPH
- Operating Temperature - Junction: -55°C ~ 125°C
