SM22-TP
Micro Commercial Co
Micro Commercial Co
TVS DIODE 22VWM 44VC SOT23
$0.45
Available to order
Reference Price (USD)
3,000+
$0.13481
6,000+
$0.12767
15,000+
$0.12053
30,000+
$0.11220
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The SM22-TP by Micro Commercial Co is a top-tier TVS diode designed for advanced circuit protection. Featuring ultra-low capacitance and high energy absorption, this diode is perfect for high-speed data lines and sensitive electronics. TVS diodes play a vital role in protecting equipment from lightning strikes, inductive load switching, and other transient threats. Common applications include network equipment, medical devices, and automotive systems. For instance, the SM22-TP can secure CAN bus lines in vehicles against voltage spikes. Rely on Micro Commercial Co for cutting-edge TVS diode solutions.
Specifications
- Product Status: Active
- Type: Zener
- Unidirectional Channels: 2
- Bidirectional Channels: -
- Voltage - Reverse Standoff (Typ): 22V (Max)
- Voltage - Breakdown (Min): 23.5V
- Voltage - Clamping (Max) @ Ipp: 44V
- Current - Peak Pulse (10/1000µs): 3A (8/20µs)
- Power - Peak Pulse: 300W
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: 80pF @ 1MHz
- Operating Temperature: -55°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SOT-23
