SMCJ22A-M3/9AT
Vishay General Semiconductor - Diodes Division
Vishay General Semiconductor - Diodes Division
TVS DIODE 22VWM 35.5VC DO214AB
$0.35
Available to order
Reference Price (USD)
7,000+
$0.29768
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The SMCJ22A-M3/9AT by Vishay General Semiconductor - Diodes Division is a top-tier TVS diode designed for advanced circuit protection. Featuring ultra-low capacitance and high energy absorption, this diode is perfect for high-speed data lines and sensitive electronics. TVS diodes play a vital role in protecting equipment from lightning strikes, inductive load switching, and other transient threats. Common applications include network equipment, medical devices, and automotive systems. For instance, the SMCJ22A-M3/9AT can secure CAN bus lines in vehicles against voltage spikes. Rely on Vishay General Semiconductor - Diodes Division for cutting-edge TVS diode solutions.
Specifications
- Product Status: Active
- Type: Zener
- Unidirectional Channels: 1
- Bidirectional Channels: -
- Voltage - Reverse Standoff (Typ): 22V
- Voltage - Breakdown (Min): 24.4V
- Voltage - Clamping (Max) @ Ipp: 35.5V
- Current - Peak Pulse (10/1000µs): 42.3A
- Power - Peak Pulse: 1500W (1.5kW)
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: -
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: DO-214AB, SMC
- Supplier Device Package: DO-214AB (SMC)
