SN74LVC2G53DCUT
Texas Instruments
Texas Instruments
IC SWITCH SPDT SINGLE 8VSSOP
$1.03
Available to order
Reference Price (USD)
1+
$1.03000
500+
$1.0197
1000+
$1.0094
1500+
$0.9991
2000+
$0.9888
2500+
$0.9785
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Optimize your signal path design with Texas Instruments's SN74LVC2G53DCUT, a flagship product in our Analog Switches and Multiplexers category. This IC combines low distortion (<0.01% THD) with high off-isolation (>80dB at 1MHz), making it ideal for high-fidelity applications. The breakthrough architecture enables simultaneous sampling across multiple channels while maintaining signal purity. Key implementations include: industrial process control interfaces, semiconductor test handlers, MRI machine front-ends, and 5G base station signal conditioning. The SN74LVC2G53DCUT meets stringent requirements for military-grade communications equipment and satellite payload management systems, offering radiation-hardened versions upon request.
Specifications
- Product Status: Active
- Switch Circuit: SPDT
- Multiplexer/Demultiplexer Circuit: 2:1
- Number of Circuits: 1
- On-State Resistance (Max): 13Ohm
- Channel-to-Channel Matching (ΔRon): 2Ohm (Max)
- Voltage - Supply, Single (V+): 1.65V ~ 5.5V
- Voltage - Supply, Dual (V±): -
- Switch Time (Ton, Toff) (Max): 4.5ns, 8ns
- -3db Bandwidth: 300MHz
- Charge Injection: -
- Channel Capacitance (CS(off), CD(off)): 10pF
- Current - Leakage (IS(off)) (Max): 100nA
- Crosstalk: -58dB @ 1MHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 8-VFSOP (0.091", 2.30mm Width)
- Supplier Device Package: 8-VSSOP
