SQUN702E-T1_GE3
Vishay Siliconix
Vishay Siliconix
MOSFET N&P-CH COMMON DRAIN
$3.81
Available to order
Reference Price (USD)
1+
$3.81000
500+
$3.7719
1000+
$3.7338
1500+
$3.6957
2000+
$3.6576
2500+
$3.6195
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Enhance your circuit designs with the SQUN702E-T1_GE3, a premium Transistors - FETs, MOSFETs - Arrays product from Vishay Siliconix. This Discrete Semiconductor Products component is designed for optimal power handling and efficiency, featuring advanced technology to reduce switching losses. Suitable for applications such as DC-DC converters, audio amplifiers, and robotics, the SQUN702E-T1_GE3 delivers consistent and reliable operation. Vishay Siliconix's dedication to excellence ensures this MOSFET array meets the highest industry standards.
Specifications
- Product Status: Active
- FET Type: N and P-Channel, Common Drain
- FET Feature: Standard
- Drain to Source Voltage (Vdss): 40V, 200V
- Current - Continuous Drain (Id) @ 25°C: 30A (Tc), 20A (Tc)
- Rds On (Max) @ Id, Vgs: 9.2mOhm @ 9.8A, 10V, 60mOhm @ 5A, 10V, 30mOhm @ 6A, 10V
- Vgs(th) (Max) @ Id: 2.5V @ 250µA, 3.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 23nC @ 20V, 14nC @ 20V, 30.2nC @ 100V
- Input Capacitance (Ciss) (Max) @ Vds: 1474pF @ 20V, 1450pF @ 20V, 1302pF @ 100V
- Power - Max: 48W (Tc), 60W (Tc)
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Surface Mount, Wettable Flank
- Package / Case: Die
- Supplier Device Package: Die
