SSQ-149-02-G-D-RA
Samtec Inc.
Samtec Inc.
CONN RCPT 98POS 0.1 GOLD PCB R/A
$16.22
Available to order
Reference Price (USD)
1+
$14.46000
10+
$13.14800
25+
$12.81880
50+
$11.83300
100+
$11.17550
250+
$10.18944
500+
$9.53206
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The SSQ-149-02-G-D-RA Samtec Inc. Rectangular Connectors - Headers, Receptacles, and Female Sockets offer superior connectivity solutions for modern electronics. Designed with versatility in mind, these connectors support high-speed data transfer and power delivery. Their compact design and rugged build make them suitable for aerospace, military, and IoT applications. Whether you need board-to-board, cable-to-board, or wire-to-wire connections, Samtec Inc. provides reliable options. Examples include avionics systems, defense equipment, and smart home devices.
Specifications
- Product Status: Active
- Connector Type: Receptacle
- Contact Type: Forked
- Style: Board to Board or Cable
- Number of Positions: 98
- Number of Positions Loaded: All
- Pitch - Mating: 0.100" (2.54mm)
- Number of Rows: 2
- Row Spacing - Mating: 0.100" (2.54mm)
- Mounting Type: Through Hole, Right Angle
- Termination: Solder
- Fastening Type: Push-Pull
- Contact Finish - Mating: Gold
- Contact Finish Thickness - Mating: 20.0µin (0.51µm)
- Insulation Color: Black
- Insulation Height: 0.195" (4.95mm)
- Contact Length - Post: 0.100" (2.54mm)
- Operating Temperature: -55°C ~ 125°C
- Material Flammability Rating: UL94 V-0
- Contact Finish - Post: Gold
- Mated Stacking Heights: -
- Ingress Protection: -
- Features: -
- Current Rating (Amps): -
- Voltage Rating: 465VAC, 655VDC
