STG5683QTR
STMicroelectronics
STMicroelectronics
IC SWITCH DUAL SPDT 16QFN
$2.63
Available to order
Reference Price (USD)
1+
$2.63000
500+
$2.6037
1000+
$2.5774
1500+
$2.5511
2000+
$2.5248
2500+
$2.4985
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the STG5683QTR Analog Switch solution by STMicroelectronics, engineered for seamless signal management in complex electronic systems. Our Interface ICs collection provides robust multiplexing/demultiplexing capabilities with breakthrough performance metrics. These components exhibit nanosecond switching speeds, 15V analog signal handling, and ESD protection up to 2kV. The STG5683QTR delivers exceptional performance in battery-powered devices, telecom switches, automotive infotainment systems, and precision measurement instruments. Engineers trust this IC for its consistent performance in harsh temperature ranges (-40 C to +125 C) and its compatibility with both digital control signals and analog waveforms.
Specifications
- Product Status: Obsolete
- Switch Circuit: SPDT
- Multiplexer/Demultiplexer Circuit: 2:1
- Number of Circuits: 2
- On-State Resistance (Max): 550mOhm
- Channel-to-Channel Matching (ΔRon): 15mOhm
- Voltage - Supply, Single (V+): 1.65V ~ 4.5V
- Voltage - Supply, Dual (V±): -
- Switch Time (Ton, Toff) (Max): 80ns, 50ns
- -3db Bandwidth: 33MHz
- Charge Injection: 46pC
- Channel Capacitance (CS(off), CD(off)): 6pF
- Current - Leakage (IS(off)) (Max): -
- Crosstalk: -60dB @ 100kHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 16-UFQFN
- Supplier Device Package: 16-QFN (2.6x1.8)
