STTH75S12W
STMicroelectronics
STMicroelectronics
DIODE GEN PURP 1.2KV 75A DO247
$5.78
Available to order
Reference Price (USD)
1+
$4.12000
30+
$3.49867
120+
$3.03225
510+
$2.58129
1,020+
$2.17700
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The STTH75S12W by STMicroelectronics is a top-tier single rectifier diode designed for high-efficiency power conversion. Belonging to the Diodes - Rectifiers - Single category, it features ultra-fast recovery times and minimal power dissipation, making it perfect for switch-mode power supplies and DC-DC converters. Its versatile applications span industrial motor drives, solar inverters, and consumer electronics, where consistent performance is essential. Engineered for durability, the STTH75S12W ensures long-term reliability even in harsh operating conditions. Trust STMicroelectronics for cutting-edge semiconductor solutions that drive innovation.
Specifications
- Product Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 1200 V
- Current - Average Rectified (Io): 75A
- Voltage - Forward (Vf) (Max) @ If: 3.2 V @ 75 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 55 ns
- Current - Reverse Leakage @ Vr: 50 µA @ 1200 V
- Capacitance @ Vr, F: -
- Mounting Type: Through Hole
- Package / Case: DO-247-2 (Straight Leads)
- Supplier Device Package: DO-247
- Operating Temperature - Junction: -40°C ~ 175°C
