STW69N65M5
STMicroelectronics
STMicroelectronics
MOSFET N-CH 650V 58A TO247
$20.54
Available to order
Reference Price (USD)
1+
$21.51000
30+
$18.09100
120+
$16.62433
510+
$14.17955
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Meet the STW69N65M5 by STMicroelectronics, a high-efficiency single MOSFET engineered for superior performance in the Discrete Semiconductor Products arena. Featuring low gate drive requirements and high switching frequency, this component is perfect for RF applications, power tools, and HVAC systems. The STW69N65M5 stands out in the Transistors - FETs, MOSFETs - Single category for its rugged design and consistent output. Choose quality, choose STMicroelectronics.
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 650 V
- Current - Continuous Drain (Id) @ 25°C: 58A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 10V
- Rds On (Max) @ Id, Vgs: 45mOhm @ 29A, 10V
- Vgs(th) (Max) @ Id: 5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 143 nC @ 10 V
- Vgs (Max): ±25V
- Input Capacitance (Ciss) (Max) @ Vds: 6420 pF @ 100 V
- FET Feature: -
- Power Dissipation (Max): 330W (Tc)
- Operating Temperature: 150°C (TJ)
- Mounting Type: Through Hole
- Supplier Device Package: TO-247-3
- Package / Case: TO-247-3
