TLV70732DQNT

Texas Instruments

Manufacturer

Texas Instruments

Description:

IC REG LINEAR 3.2V 200MA 4X2SON

Datasheet:

TLV70732DQNT Datasheet

$0.95

Available to order

Reference Price (USD)

$0.95000

500+

$0.9405

1000+

$0.931

1500+

$0.9215

2000+

$0.912

2500+

$0.9025

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

The TLV70732DQNT from Texas Instruments is a high-performance linear voltage regulator IC designed for precision power management applications. As part of our PMIC - Voltage Regulators - Linear collection, this component offers exceptional voltage regulation with low dropout characteristics. Featuring thermal shutdown protection and current limiting, this IC maintains stable output voltage even under varying load conditions. These linear regulators are ideal for noise-sensitive applications requiring clean power delivery, such as medical devices, audio equipment, and precision measurement instruments. Typical implementations include power conditioning for microcontroller systems, battery-powered devices, and as post-regulators for switching power supplies.

Specifications

Product Status: Active
Output Configuration: Positive
Output Type: Fixed
Number of Regulators: 1
Voltage - Input (Max): 5.5V
Voltage - Output (Min/Fixed): 3.2V
Voltage - Output (Max): -
Voltage Dropout (Max): 0.27V @ 150mA
Current - Output: 200mA
Current - Quiescent (Iq): 50 µA
Current - Supply (Max): -
PSRR: 70dB ~ 50dB (100Hz ~ 1MHz)
Control Features: Enable
Protection Features: Over Current, Over Temperature, Short Circuit, Reverse Polarity
Operating Temperature: -40°C ~ 125°C (TJ)
Mounting Type: Surface Mount
Package / Case: 4-XDFN Exposed Pad
Supplier Device Package: 4-X2SON (1x1)
