TLV7113330DDSET

Texas Instruments

Manufacturer

Texas Instruments

Description:

IC REG LIN 3.3V/3V 200MA 6WSON

Datasheet:

TLV7113330DDSET Datasheet

$1.34

Available to order

Reference Price (USD)

250+

$0.40420

500+

$0.34400

1,250+

$0.27520

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

Texas Instruments's TLV7113330DDSET represents the cutting edge in linear voltage regulator technology within our Integrated Circuits (ICs) inventory. This PMIC component delivers fixed or adjustable output voltages with outstanding line and load regulation performance. The device incorporates advanced protection features including over-temperature and short-circuit protection, making it exceptionally reliable for critical applications. Linear voltage regulators like the TLV7113330DDSET are fundamental in automotive electronics (for infotainment systems and ECUs), industrial control systems, and telecommunications infrastructure where voltage stability is paramount. Engineers particularly value these ICs for their simplicity of design and minimal external component requirements.

Specifications

Product Status: Active
Output Configuration: Positive
Output Type: Fixed
Number of Regulators: 2
Voltage - Input (Max): 5.5V
Voltage - Output (Min/Fixed): 3.3V, 3V
Voltage - Output (Max): -
Voltage Dropout (Max): 0.2V @ 200mA, 0.215V @ 200mA
Current - Output: 200mA
Current - Quiescent (Iq): 110 µA
Current - Supply (Max): -
PSRR: 80dB ~ 50dB (10Hz ~ 100kHz)
Control Features: Enable
Protection Features: Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Operating Temperature: -40°C ~ 125°C (TJ)
Mounting Type: Surface Mount
Package / Case: 6-WFDFN
Supplier Device Package: 6-WSON (1.5x1.5)
