TPH9R506PL,LQ
Toshiba Semiconductor and Storage
Toshiba Semiconductor and Storage
MOSFET N-CH 60V 34A 8SOP
$0.79
Available to order
Reference Price (USD)
1+
$0.79000
500+
$0.7821
1000+
$0.7742
1500+
$0.7663
2000+
$0.7584
2500+
$0.7505
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The TPH9R506PL,LQ from Toshiba Semiconductor and Storage sets new standards in the Transistors - FETs, MOSFETs - Single market. This Discrete Semiconductor Product delivers exceptional performance in switching regulators, class D amplifiers, and power management ICs. Featuring advanced silicon technology and robust packaging, it's built to withstand rigorous operating conditions. When quality matters, professionals turn to Toshiba Semiconductor and Storage's TPH9R506PL,LQ for their critical applications.
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 60 V
- Current - Continuous Drain (Id) @ 25°C: 34A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 9.5mOhm @ 17A, 10V
- Vgs(th) (Max) @ Id: 2.5V @ 200µA
- Gate Charge (Qg) (Max) @ Vgs: 21 nC @ 10 V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 1910 pF @ 30 V
- FET Feature: -
- Power Dissipation (Max): 830mW (Ta), 81W (Tc)
- Operating Temperature: 175°C
- Mounting Type: Surface Mount
- Supplier Device Package: 8-SOP Advance (5x5)
- Package / Case: 8-PowerVDFN
