TPS2069CDGN-2
Texas Instruments
Texas Instruments
IC PWR SWITCH N-CHAN 1:1 8MSOP
$1.11
Available to order
Reference Price (USD)
400+
$1.48010
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The TPS2069CDGN-2 Load Driver IC by Texas Instruments is a versatile solution for modern power distribution challenges. Part of the PMIC family, this IC provides precise load driving capabilities with built-in safeguards like short-circuit and overvoltage protection. From smart home appliances to medical equipment, the TPS2069CDGN-2 delivers consistent performance. Its compact design and energy-saving features make it a favorite among engineers. Choose Texas Instruments for ICs that combine power, precision, and protection in one advanced package.
Specifications
- Product Status: Active
- Switch Type: USB Switch
- Number of Outputs: 1
- Ratio - Input:Output: 1:1
- Output Configuration: High Side
- Output Type: N-Channel
- Interface: On/Off
- Voltage - Load: 4.5V ~ 5.5V
- Voltage - Supply (Vcc/Vdd): Not Required
- Current - Output (Max): 1.5A
- Rds On (Typ): 69mOhm
- Input Type: Non-Inverting
- Features: Status Flag
- Fault Protection: Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: 8-HVSSOP
- Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
