TPS72710DSET

Texas Instruments

Manufacturer

Texas Instruments

Description:

IC REG LINEAR 1V 250MA 6WSON

Datasheet:

TPS72710DSET Datasheet

$1.83

Available to order

Reference Price (USD)

$1.83000

500+

$1.8117

1000+

$1.7934

1500+

$1.7751

2000+

$1.7568

2500+

$1.7385

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

The TPS72710DSET from Texas Instruments is a high-performance linear voltage regulator IC designed for precision power management applications. As part of our PMIC - Voltage Regulators - Linear collection, this component offers exceptional voltage regulation with low dropout characteristics. Featuring thermal shutdown protection and current limiting, this IC maintains stable output voltage even under varying load conditions. These linear regulators are ideal for noise-sensitive applications requiring clean power delivery, such as medical devices, audio equipment, and precision measurement instruments. Typical implementations include power conditioning for microcontroller systems, battery-powered devices, and as post-regulators for switching power supplies.

Specifications

Product Status: Active
Output Configuration: Positive
Output Type: Fixed
Number of Regulators: 1
Voltage - Input (Max): 5.5V
Voltage - Output (Min/Fixed): 1V
Voltage - Output (Max): -
Voltage Dropout (Max): 0.2V @ 200mA
Current - Output: 250mA
Current - Quiescent (Iq): 110 µA
Current - Supply (Max): 130 µA
PSRR: 85dB ~ 45dB (10Hz ~ 1MHz)
Control Features: Enable
Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Operating Temperature: -40°C ~ 125°C
Mounting Type: Surface Mount
Package / Case: 6-WFDFN
Supplier Device Package: 6-WSON (1.5x1.5)
