TPS7A6301QPWPRQ1

Texas Instruments

Manufacturer

Texas Instruments

Description:

IC REG LIN POS ADJ 14HTSSOP

Datasheet:

TPS7A6301QPWPRQ1 Datasheet

$1.04

Available to order

Reference Price (USD)

2,000+

$1.16370

6,000+

$1.12060

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

Discover the TPS7A6301QPWPRQ1 linear voltage regulator IC by Texas Instruments, a standout product in our PMIC - Voltage Regulators - Linear category. This IC provides precise voltage regulation with ultra-low noise output, making it perfect for analog and RF circuits. The device features excellent PSRR (Power Supply Rejection Ratio) performance and comes in various package options to suit different design requirements. Linear regulators such as this TPS7A6301QPWPRQ1 model are extensively used in consumer electronics (smartphones, tablets), IoT devices, and aerospace applications where consistent voltage without switching noise is essential. Its robust design ensures reliable operation in harsh environments with wide temperature ranges.

Specifications

Product Status: Active
Output Configuration: Positive
Output Type: Adjustable
Number of Regulators: 1
Voltage - Input (Max): 40V
Voltage - Output (Min/Fixed): 2.5V
Voltage - Output (Max): 7V
Voltage Dropout (Max): 0.5V @ 250mA
Current - Output: 200mA
Current - Quiescent (Iq): 35 µA
Current - Supply (Max): -
PSRR: 60dB ~ 30dB (100Hz ~ 150kHz)
Control Features: Enable
Protection Features: Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Operating Temperature: -40°C ~ 150°C
Mounting Type: Surface Mount
Package / Case: 14-TSSOP (0.173", 4.40mm Width) Exposed Pad
Supplier Device Package: 14-HTSSOP
