TPS7A8301ARGRR

Texas Instruments

Manufacturer

Texas Instruments

Description:

IC POWER

Datasheet:

TPS7A8301ARGRR Datasheet

$2.62

Available to order

Reference Price (USD)

$2.62240

500+

$2.596176

1000+

$2.569952

1500+

$2.543728

2000+

$2.517504

2500+

$2.49128

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

The TPS7A8301ARGRR by Texas Instruments is a high-efficiency PMIC - Voltage Regulators - Linear IC designed to meet the needs of today's advanced electronic systems. This IC offers superior voltage regulation with features like fast transient response, low noise, and high accuracy. Its robust construction ensures long-term reliability, making it a perfect fit for both commercial and industrial applications. In the PMIC - Voltage Regulators - Linear category, the TPS7A8301ARGRR stands out for its ability to handle varying load conditions without compromising performance. It provides excellent line regulation and low quiescent current, which are essential for energy-efficient designs. Additionally, its built-in protection mechanisms safeguard against over-voltage and short-circuit conditions. The TPS7A8301ARGRR is employed in diverse fields, including medical imaging, consumer electronics, and military equipment. For instance, it is used in MRI machines, high-end audio systems, and defense communication devices. Its versatility and dependable performance make it a cornerstone in modern electronic engineering.

Specifications

Product Status: Active
Output Configuration: Positive
Output Type: Adjustable
Number of Regulators: 1
Voltage - Input (Max): 6.5V
Voltage - Output (Min/Fixed): 0.5V
Voltage - Output (Max): 5.2V
Voltage Dropout (Max): 0.3V @ 2A
Current - Output: 2A
Current - Quiescent (Iq): 4 mA
Current - Supply (Max): 5 mA
PSRR: 42dB ~ 25dB (10kHz ~ 500kHz)
Control Features: Current Limit, Enable, Power Good, Soft Start
Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Operating Temperature: -40°C ~ 125°C (TJ)
Mounting Type: Surface Mount
Package / Case: 20-VFQFN Exposed Pad
Supplier Device Package: 20-VQFN (3.5x3.5)
