TXN825RG
STMicroelectronics
STMicroelectronics
SCR 800MV 25A TO220AB
$1.24
Available to order
Reference Price (USD)
1+
$1.24180
500+
$1.229382
1000+
$1.216964
1500+
$1.204546
2000+
$1.192128
2500+
$1.17971
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The TXN825RG Silicon Controlled Rectifier from STMicroelectronics sets new standards in the Discrete Semiconductor Products market. As part of the Thyristors - SCRs classification, it offers unmatched surge protection and switching speed. Primary application areas include electric arc furnaces, laser power supplies, and DC motor drives. For instance, it's crucial in steel production facilities. With STMicroelectronics's technological leadership, the TXN825RG guarantees peak performance in extreme conditions.
Specifications
- Product Status: Active
- Voltage - Off State: 800 V
- Voltage - Gate Trigger (Vgt) (Max): 1.3 V
- Current - Gate Trigger (Igt) (Max): 40 mA
- Voltage - On State (Vtm) (Max): 1.6 V
- Current - On State (It (AV)) (Max): 16 A
- Current - On State (It (RMS)) (Max): 25 A
- Current - Hold (Ih) (Max): 50 mA
- Current - Off State (Max): 5 µA
- Current - Non Rep. Surge 50, 60Hz (Itsm): 300A, 314A
- SCR Type: Standard Recovery
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220AB Insulated
