UA78L09ACLPR

Texas Instruments

Manufacturer

Texas Instruments

Description:

IC REG LINEAR 9V 100MA TO92-3

Datasheet:

UA78L09ACLPR Datasheet

$0.45

Available to order

Reference Price (USD)

$0.45000

500+

$0.4455

1000+

$0.441

1500+

$0.4365

2000+

$0.432

2500+

$0.4275

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

Discover the UA78L09ACLPR, a premium PMIC - Voltage Regulators - Linear IC from Texas Instruments, engineered to provide exceptional voltage regulation with minimal power loss. This IC is part of the esteemed PMIC - Voltage Regulators - Linear category, known for its ability to maintain stable voltage levels under varying load conditions. The UA78L09ACLPR excels with its low quiescent current, high efficiency, and superior thermal management, ensuring optimal performance in demanding environments. Linear voltage regulators like the UA78L09ACLPR are pivotal in applications requiring precise voltage control without the complexity of switching regulators. The UA78L09ACLPR offers outstanding line and load regulation, making it a preferred choice for sensitive electronic circuits. Its advanced protection features, including over-current and over-temperature safeguards, further enhance its reliability. The UA78L09ACLPR finds applications across multiple sectors, including medical devices, industrial automation, and consumer electronics. For example, it is used in wearable health monitors, factory automation systems, and smart home devices. Its ability to deliver clean and stable power makes it indispensable for modern electronic designs, ensuring both performance and safety.

Specifications

Product Status: Active
Output Configuration: Positive
Output Type: Fixed
Number of Regulators: 1
Voltage - Input (Max): 24V
Voltage - Output (Min/Fixed): 9V
Voltage - Output (Max): -
Voltage Dropout (Max): 1.7V @ 40mA
Current - Output: 100mA
Current - Quiescent (Iq): -
Current - Supply (Max): -
PSRR: 45dB (120Hz)
Control Features: -
Protection Features: Over Current, Over Temperature, Reverse Polarity, Short Circuit
Operating Temperature: 0°C ~ 125°C
Mounting Type: Through Hole
Package / Case: TO-226-3, TO-92-3 (TO-226AA) Formed Leads
Supplier Device Package: TO-92-3
