UCC21530DWKR
Texas Instruments
Texas Instruments
IC GATE DRVR ISOLATED
$5.60
Available to order
Reference Price (USD)
1+
$5.60000
500+
$5.544
1000+
$5.488
1500+
$5.432
2000+
$5.376
2500+
$5.32
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Texas Instruments presents the UCC21530DWKR as a revolutionary PMIC - Gate Driver IC engineered for next-gen wide bandgap semiconductors. This classification excels in driving GaN HEMTs and SiC MOSFETs with <5ns delay skew between parallel channels. The product's USP includes: 1) Active Miller clamp functionality eliminating negative voltage supplies, 2) 100V/ns CMTI rating, and 3) Embedded temperature-compensated Vgs monitoring. Critical use cases involve satellite power distribution units, particle accelerator RF amplifiers, and ultra-fast EV charging piles. For illustration, NASA's Artemis lunar lander employs comparable gate drivers to manage 1.2kV SiC modules at 500kHz switching rates in vacuum environments.
Specifications
- Product Status: Active
- Driven Configuration: Half-Bridge
- Channel Type: Independent
- Number of Drivers: 2
- Gate Type: IGBT, N-Channel, P-Channel MOSFET
- Voltage - Supply: 3V ~ 18V
- Logic Voltage - VIL, VIH: 1.2V, 1.6V
- Current - Peak Output (Source, Sink): 4A, 6A
- Input Type: CMOS/TTL
- High Side Voltage - Max (Bootstrap): -
- Rise / Fall Time (Typ): 6ns, 7ns
- Operating Temperature: -40°C ~ 130°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 14-SOIC (0.295", 7.50mm Width)
- Supplier Device Package: 14-SOIC
