UCC21530QDWKRQ1
Texas Instruments
Texas Instruments
IC GATE DRVR ISOLATED
$6.43
Available to order
Reference Price (USD)
1+
$6.43000
500+
$6.3657
1000+
$6.3014
1500+
$6.2371
2000+
$6.1728
2500+
$6.1085
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Texas Instruments's UCC21530QDWKRQ1 represents the cutting edge of PMIC - Gate Driver technology, engineered to deliver unmatched switching performance for power electronics. This IC classification specializes in synchronous rectification and half-bridge configurations with integrated bootstrap diodes. Notable characteristics comprise UVLO protection, programmable turn-on/off thresholds, and 4A peak output current capacity. Primary applications span data center power supplies, welding equipment, and DC-DC converters. A concrete example: the UCC21530QDWKRQ1 enables 98% efficiency in 1kW telecom power modules while withstanding 100V/ns common-mode transients. The device's reinforced isolation meets IEC 61800-5-1 standards, particularly valuable for medical imaging systems and railway traction converters.
Specifications
- Product Status: Active
- Driven Configuration: Half-Bridge
- Channel Type: Independent
- Number of Drivers: 2
- Gate Type: IGBT, N-Channel, P-Channel MOSFET
- Voltage - Supply: 3V ~ 18V
- Logic Voltage - VIL, VIH: 1.2V, 1.6V
- Current - Peak Output (Source, Sink): 4A, 6A
- Input Type: CMOS/TTL
- High Side Voltage - Max (Bootstrap): -
- Rise / Fall Time (Typ): 6ns, 7ns
- Operating Temperature: -40°C ~ 130°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 14-SOIC (0.295", 7.50mm Width)
- Supplier Device Package: 14-SOIC
