UCD7100PWP
Texas Instruments
Texas Instruments
IC GATE DRVR LOW-SIDE 14HTSSOP
$1.71
Available to order
Reference Price (USD)
1+
$2.66000
10+
$2.38700
90+
$2.25678
180+
$1.95583
540+
$1.66498
1,080+
$1.40420
2,520+
$1.33399
5,040+
$1.28384
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The UCD7100PWP from Texas Instruments redefines compact power management as a space-optimized PMIC - Gate Driver IC. Measuring just 3x3mm QFN, this classification achieves 5kV reinforced isolation through innovative transformer coupling technology. Signature features are: 1) 50% lower quiescent current than industry average, 2) 3.3V/5V logic level translation, and 3) Lead-free/RoHS 3.0 compliance. Consumer electronics particularly benefit in wireless charging pads (Qi 1.3 standard), drone ESC modules, and VR headset power circuits. Real-world testing demonstrates the UCD7100PWP enabling 95W USB-PD adapters at 30W/in power density - a key enabler for Apple's MagSafe ecosystem.
Specifications
- Product Status: Active
- Driven Configuration: Low-Side
- Channel Type: Single
- Number of Drivers: 1
- Gate Type: N-Channel MOSFET
- Voltage - Supply: 4.25V ~ 15V
- Logic Voltage - VIL, VIH: 1.16V, 2.08V
- Current - Peak Output (Source, Sink): 4A, 4A
- Input Type: Non-Inverting
- High Side Voltage - Max (Bootstrap): -
- Rise / Fall Time (Typ): 10ns, 10ns
- Operating Temperature: -40°C ~ 105°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 14-TSSOP (0.173", 4.40mm Width) Exposed Pad
- Supplier Device Package: 14-HTSSOP
