US1M-13-F
Diodes Incorporated
Diodes Incorporated
DIODE GEN PURP 1KV 1A SMA
$0.47
Available to order
Reference Price (USD)
5,000+
$0.08500
10,000+
$0.07750
25,000+
$0.07250
50,000+
$0.07000
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The US1M-13-F by Diodes Incorporated is a top-tier single rectifier diode designed for high-efficiency power conversion. Belonging to the Diodes - Rectifiers - Single category, it features ultra-fast recovery times and minimal power dissipation, making it perfect for switch-mode power supplies and DC-DC converters. Its versatile applications span industrial motor drives, solar inverters, and consumer electronics, where consistent performance is essential. Engineered for durability, the US1M-13-F ensures long-term reliability even in harsh operating conditions. Trust Diodes Incorporated for cutting-edge semiconductor solutions that drive innovation.
Specifications
- Product Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 1000 V
- Current - Average Rectified (Io): 1A
- Voltage - Forward (Vf) (Max) @ If: 1.7 V @ 1 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 75 ns
- Current - Reverse Leakage @ Vr: 5 µA @ 1000 V
- Capacitance @ Vr, F: 10pF @ 4V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: DO-214AC, SMA
- Supplier Device Package: SMA
- Operating Temperature - Junction: -65°C ~ 150°C
