Coaxial Connectors (RF)

Coaxial Connectors (RF) - Category Overview

1. Definition of Coaxial Connectors (RF)
Coaxial Connectors (RF) are specialized interconnects designed to transmit high-frequency signals with minimal signal loss and electromagnetic interference (EMI). These connectors feature a concentric design, with an inner conductor surrounded by a tubular insulating layer and an outer conductive shield, ensuring optimal impedance matching (typically 50 or 75 ) for radio frequency (RF) applications. They are critical components in telecommunications, aerospace, military, and consumer electronics where signal integrity is paramount.

2. Types of Coaxial Connectors (RF)
This category includes a diverse range of connector types, each tailored for specific performance requirements:
- Standard RF Connectors: BNC, SMA, SMB, and TNC connectors for general-purpose RF connectivity.
- High-Frequency/Precision Connectors: N-type, 7/16 DIN, and APC-7 connectors for demanding applications like 5G infrastructure and test equipment.
- Miniature Connectors: MCX, MMCX, and SMP connectors for space-constrained designs (e.g., IoT devices, wearables).
- Waterproof/Shielded Variants: IP-rated connectors for harsh environments (e.g., marine, industrial).

3. Purchasing Recommendations
When selecting Coaxial Connectors (RF), consider:
- Frequency Range: Match the connector s rated frequency (e.g., SMA up to 18 GHz, N-type up to 11 GHz) to your application.
- Impedance: Ensure compatibility (50 for most RF systems; 75 for video/CATV).
- Durability: Opt for gold-plated contacts or stainless steel bodies for high-cycle or outdoor use.
- Certifications: Look for MIL-SPEC, RoHS, or REACH compliance if required.

Trust our curated selection of Coaxial Connectors (RF) to deliver unmatched signal performance and reliability for your interconnect solutions.

Found 23096 items
