FDD6776A
Fairchild Semiconductor
Fairchild Semiconductor
MOSFET N-CH 25V 17.7A/30A DPAK
$0.37
Available to order
Reference Price (USD)
1+
$0.37000
500+
$0.3663
1000+
$0.3626
1500+
$0.3589
2000+
$0.3552
2500+
$0.3515
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The FDD6776A by Fairchild Semiconductor is a premium single MOSFET belonging to the Transistors - FETs, MOSFETs - Single classification. Known for its robust construction and high efficiency, this component is perfect for switching and amplification tasks. Key features include low gate charge, high current capability, and superior thermal performance. Commonly used in automotive systems, industrial automation, and renewable energy solutions, the FDD6776A is a versatile choice for engineers seeking top-tier Discrete Semiconductor Products.
Specifications
- Product Status: Obsolete
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 25 V
- Current - Continuous Drain (Id) @ 25°C: 17.7A (Ta), 30A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 7.5mOhm @ 17.7A, 10V
- Vgs(th) (Max) @ Id: 3V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 29 nC @ 10 V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 1490 pF @ 13 V
- FET Feature: -
- Power Dissipation (Max): 3.7W (Ta), 39W (Tc)
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: TO-252, (D-Pak)
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
