FDS6690
Fairchild Semiconductor
Fairchild Semiconductor
SMALL SIGNAL N-CHANNEL MOSFET
$1.01
Available to order
Reference Price (USD)
1+
$1.01000
500+
$0.9999
1000+
$0.9898
1500+
$0.9797
2000+
$0.9696
2500+
$0.9595
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Meet the FDS6690 by Fairchild Semiconductor, a high-efficiency single MOSFET engineered for superior performance in the Discrete Semiconductor Products arena. Featuring low gate drive requirements and high switching frequency, this component is perfect for RF applications, power tools, and HVAC systems. The FDS6690 stands out in the Transistors - FETs, MOSFETs - Single category for its rugged design and consistent output. Choose quality, choose Fairchild Semiconductor.
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 30 V
- Current - Continuous Drain (Id) @ 25°C: 10A (Ta)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 13.5mOhm @ 10A, 10V
- Vgs(th) (Max) @ Id: 3V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 18 nC @ 5 V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 1340 pF @ 15 V
- FET Feature: -
- Power Dissipation (Max): 1W (Ta)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: 8-SOIC
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
