HMTMS-145-25-T-D-115
Samtec Inc.
Samtec Inc.
CONN HDR .050" 90POS
$11.33
Available to order
Reference Price (USD)
1+
$11.33000
500+
$11.2167
1000+
$11.1034
1500+
$10.9901
2000+
$10.8768
2500+
$10.7635
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The HMTMS-145-25-T-D-115 by Samtec Inc. is a versatile rectangular connector header designed for male pin connections. With a focus on quality and precision, these headers support various PCB layouts and configurations. Ideal for applications in robotics, power supplies, and audio equipment. Samtec Inc. delivers connectors that meet the needs of modern electronics with unmatched reliability.
Specifications
- Product Status: Active
- Connector Type: Header
- Contact Type: Male Pin
- Pitch - Mating: 0.050" (1.27mm)
- Number of Positions: 90
- Number of Rows: 2
- Row Spacing - Mating: 0.100" (2.54mm)
- Number of Positions Loaded: All
- Style: Board to Board
- Shrouding: Unshrouded
- Mounting Type: Through Hole
- Termination: Solder
- Fastening Type: Push-Pull
- Contact Length - Mating: 0.115" (2.92mm)
- Contact Length - Post: 0.115" (2.92mm)
- Overall Contact Length: 0.330" (8.38mm)
- Insulation Height: 0.100" (2.54mm)
- Contact Shape: Square
- Contact Finish - Mating: Tin
- Contact Finish Thickness - Mating: -
- Contact Finish - Post: Tin
- Contact Material: Phosphor Bronze
- Insulation Material: Liquid Crystal Polymer (LCP)
- Features: -
- Operating Temperature: -55°C ~ 105°C
- Ingress Protection: -
- Material Flammability Rating: -
- Insulation Color: Black
- Current Rating (Amps): -
- Voltage Rating: -
