IXTA140P05T
IXYS
IXYS
MOSFET P-CH 50V 140A TO263
$7.91
Available to order
Reference Price (USD)
50+
$4.88260
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the IXTA140P05T from IXYS, a high-performance single MOSFET designed for efficient power management in modern electronics. As part of the Discrete Semiconductor Products category, this transistor offers low on-resistance, fast switching speeds, and excellent thermal stability. Ideal for applications such as power supplies, motor control, and LED lighting, the IXTA140P05T ensures reliable performance in demanding environments. Upgrade your circuit designs with IXYS's cutting-edge technology today.
Specifications
- Product Status: Active
- FET Type: P-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 50 V
- Current - Continuous Drain (Id) @ 25°C: 140A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 10V
- Rds On (Max) @ Id, Vgs: 9mOhm @ 70A, 10V
- Vgs(th) (Max) @ Id: 4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 200 nC @ 10 V
- Vgs (Max): ±15V
- Input Capacitance (Ciss) (Max) @ Vds: 13500 pF @ 25 V
- FET Feature: -
- Power Dissipation (Max): 298W (Tc)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: TO-263AA
- Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Related Products
Alpha & Omega Semiconductor Inc.
AOI4286
Rectron USA
RM21N700TI
Fairchild Semiconductor
IRLR130ATM
Diodes Incorporated
DMTH10H072LPS-13
onsemi
NVMFS5C450NWFAFT1G
onsemi
NVBLS1D7N08H
Infineon Technologies
ISP25DP06LMXTSA1
Infineon Technologies
IPU80R1K2P7AKMA1
EPC
EPC2302
