LM5101M/NOPB
Texas Instruments
Texas Instruments
IC GATE DRVR HALF-BRIDGE 8SOIC
$4.80
Available to order
Reference Price (USD)
1+
$3.92000
10+
$3.51800
95+
$3.32547
190+
$2.88211
570+
$2.45347
1,045+
$2.06920
2,565+
$1.96574
5,035+
$1.89184
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The LM5101M/NOPB from Texas Instruments is a high-performance PMIC - Gate Driver IC designed for precision control in power management applications. This integrated circuit excels in driving MOSFETs and IGBTs with exceptional speed and reliability, making it ideal for high-frequency switching systems. Key features include robust noise immunity, low propagation delay, and adaptive dead-time control to optimize efficiency. These gate drivers are widely used in industrial motor controls, solar inverters, and electric vehicle powertrains. For instance, the LM5101M/NOPB ensures seamless operation in servo drives requiring nanosecond-level response times. Its compact design and thermal protection mechanisms further enhance system longevity in demanding environments like factory automation and renewable energy systems.
Specifications
- Product Status: Not For New Designs
- Driven Configuration: Half-Bridge
- Channel Type: Independent
- Number of Drivers: 2
- Gate Type: N-Channel MOSFET
- Voltage - Supply: 9V ~ 14V
- Logic Voltage - VIL, VIH: 0.8V, 2.2V
- Current - Peak Output (Source, Sink): 1.6A, 1.6A
- Input Type: Non-Inverting
- High Side Voltage - Max (Bootstrap): 118 V
- Rise / Fall Time (Typ): 600ns, 600ns
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
