NTHL020N120SC1
onsemi
onsemi
SICFET N-CH 1200V 103A TO247-3
$53.04
Available to order
Reference Price (USD)
1+
$53.04000
500+
$52.5096
1000+
$51.9792
1500+
$51.4488
2000+
$50.9184
2500+
$50.388
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The NTHL020N120SC1 single MOSFET from onsemi is a game-changer in power electronics. As part of the Discrete Semiconductor Products family, it offers unparalleled efficiency in energy conversion and management. Key applications include uninterruptible power supplies (UPS), welding equipment, and industrial motor drives. With features like high temperature operation and ESD protection, the NTHL020N120SC1 is a must-have in the Transistors - FETs, MOSFETs - Single category.
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: SiCFET (Silicon Carbide)
- Drain to Source Voltage (Vdss): 1200 V
- Current - Continuous Drain (Id) @ 25°C: 103A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 20V
- Rds On (Max) @ Id, Vgs: 28mOhm @ 60A, 20V
- Vgs(th) (Max) @ Id: 4.3V @ 20mA
- Gate Charge (Qg) (Max) @ Vgs: 203 nC @ 20 V
- Vgs (Max): +25V, -15V
- Input Capacitance (Ciss) (Max) @ Vds: 2890 pF @ 800 V
- FET Feature: -
- Power Dissipation (Max): 535W (Tc)
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Through Hole
- Supplier Device Package: TO-247-3
- Package / Case: TO-247-3
