NVMFS6H818NLT1G
onsemi
onsemi
MOSFET N-CH 80V 22A/135A 5DFN
$4.66
Available to order
Reference Price (USD)
1+
$4.66000
500+
$4.6134
1000+
$4.5668
1500+
$4.5202
2000+
$4.4736
2500+
$4.427
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The NVMFS6H818NLT1G by onsemi is a standout in the Transistors - FETs, MOSFETs - Single segment, offering exceptional power handling and efficiency. Designed for precision and reliability, this MOSFET is widely used in audio amplifiers, DC-DC converters, and battery management systems. With advanced features like avalanche energy resistance and low leakage current, it's a top pick for professionals in the Discrete Semiconductor Products field. Choose onsemi for innovation you can depend on.
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 80 V
- Current - Continuous Drain (Id) @ 25°C: 22A (Ta), 135A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 3.2mOhm @ 20A, 10V
- Vgs(th) (Max) @ Id: 2V @ 190µA
- Gate Charge (Qg) (Max) @ Vgs: 64 nC @ 10 V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 3844 pF @ 40 V
- FET Feature: -
- Power Dissipation (Max): 3.8W (Ta), 140W (Tc)
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: 5-DFN (5x6) (8-SOFL)
- Package / Case: 8-PowerTDFN, 5 Leads
