PJP10NA80_T0_00001
Panjit International Inc.
Panjit International Inc.
800V N-CHANNEL MOSFET
$2.72
Available to order
Reference Price (USD)
1+
$2.72000
500+
$2.6928
1000+
$2.6656
1500+
$2.6384
2000+
$2.6112
2500+
$2.584
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The PJP10NA80_T0_00001 from Panjit International Inc. sets new standards in the Transistors - FETs, MOSFETs - Single market. This Discrete Semiconductor Product delivers exceptional performance in switching regulators, class D amplifiers, and power management ICs. Featuring advanced silicon technology and robust packaging, it's built to withstand rigorous operating conditions. When quality matters, professionals turn to Panjit International Inc.'s PJP10NA80_T0_00001 for their critical applications.
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 800 V
- Current - Continuous Drain (Id) @ 25°C: 10A (Ta)
- Drive Voltage (Max Rds On, Min Rds On): 10V
- Rds On (Max) @ Id, Vgs: 1.15Ohm @ 5A, 10V
- Vgs(th) (Max) @ Id: 4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 31 nC @ 10 V
- Vgs (Max): ±30V
- Input Capacitance (Ciss) (Max) @ Vds: 1517 pF @ 25 V
- FET Feature: -
- Power Dissipation (Max): 180W (Tc)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Supplier Device Package: TO-220AB
- Package / Case: TO-220-3
