STP22N60M6

STMicroelectronics
STP22N60M6 Preview
STMicroelectronics
MOSFET N-CH 600V 15A TO220
$1.78
Available to order
Reference Price (USD)
1+
$1.77660
500+
$1.758834
1000+
$1.741068
1500+
$1.723302
2000+
$1.705536
2500+
$1.68777
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram

Specifications

  • Product Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 600 V
  • Current - Continuous Drain (Id) @ 25°C: 15A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 230mOhm @ 7.5A, 10V
  • Vgs(th) (Max) @ Id: 4.75V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 20 nC @ 10 V
  • Vgs (Max): ±25V
  • Input Capacitance (Ciss) (Max) @ Vds: 800 pF @ 100 V
  • FET Feature: -
  • Power Dissipation (Max): 130W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-220
  • Package / Case: TO-220-3
