TPH1R405PL,L1Q
Toshiba Semiconductor and Storage
Toshiba Semiconductor and Storage
MOSFET N-CH 45V 120A 8SOP
$1.51
Available to order
Reference Price (USD)
1+
$1.51000
500+
$1.4949
1000+
$1.4798
1500+
$1.4647
2000+
$1.4496
2500+
$1.4345
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Meet the TPH1R405PL,L1Q by Toshiba Semiconductor and Storage, a high-efficiency single MOSFET engineered for superior performance in the Discrete Semiconductor Products arena. Featuring low gate drive requirements and high switching frequency, this component is perfect for RF applications, power tools, and HVAC systems. The TPH1R405PL,L1Q stands out in the Transistors - FETs, MOSFETs - Single category for its rugged design and consistent output. Choose quality, choose Toshiba Semiconductor and Storage.
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 45 V
- Current - Continuous Drain (Id) @ 25°C: 120A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 1.4mOhm @ 50A, 10V
- Vgs(th) (Max) @ Id: 2.4V @ 500µA
- Gate Charge (Qg) (Max) @ Vgs: 74 nC @ 10 V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 6300 pF @ 22.5 V
- FET Feature: -
- Power Dissipation (Max): 960mW (Ta), 132W (Tc)
- Operating Temperature: 175°C
- Mounting Type: Surface Mount
- Supplier Device Package: 8-SOP Advance (5x5)
- Package / Case: 8-PowerVDFN
