TS3A5018D
Texas Instruments
Texas Instruments
IC SWITCH QUAD SPDT 16SOIC
$0.96
Available to order
Reference Price (USD)
1+
$0.96000
500+
$0.9504
1000+
$0.9408
1500+
$0.9312
2000+
$0.9216
2500+
$0.912
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The TS3A5018D from Texas Instruments's Analog Switch/Mux/Demux series revolutionizes signal routing with its integrated fault detection circuitry. This Interface IC automatically reports channel integrity issues while maintaining <100pA leakage at elevated temperatures. Its dual-supply architecture ( 5V to 20V) accommodates industrial process signals without additional level shifting. The TS3A5018D is extensively used in: semiconductor wafer probers, phased-array antenna controllers, electrophysiology lab equipment, and smart factory robotic arms. Its -60dB crosstalk performance at 10MHz makes it indispensable for high-speed data acquisition systems and spectrum analyzer front-ends.
Specifications
- Product Status: Active
- Switch Circuit: SPDT
- Multiplexer/Demultiplexer Circuit: 2:1
- Number of Circuits: 4
- On-State Resistance (Max): 10Ohm
- Channel-to-Channel Matching (ΔRon): 300mOhm
- Voltage - Supply, Single (V+): 1.65V ~ 3.6V
- Voltage - Supply, Dual (V±): -
- Switch Time (Ton, Toff) (Max): 8ns, 6.5ns
- -3db Bandwidth: 300MHz
- Charge Injection: 2pC
- Channel Capacitance (CS(off), CD(off)): 4.5pF, 9pF
- Current - Leakage (IS(off)) (Max): 100nA
- Crosstalk: -48dB @ 10MHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 16-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 16-SOIC
