CPH3456-TL-W
onsemi
onsemi
MOSFET N-CH 20V 3.5A 3CPH
$0.12
Available to order
Reference Price (USD)
3,000+
$0.11271
6,000+
$0.10588
15,000+
$0.09905
30,000+
$0.09085
75,000+
$0.08744
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Meet the CPH3456-TL-W by onsemi, a high-efficiency single MOSFET engineered for superior performance in the Discrete Semiconductor Products arena. Featuring low gate drive requirements and high switching frequency, this component is perfect for RF applications, power tools, and HVAC systems. The CPH3456-TL-W stands out in the Transistors - FETs, MOSFETs - Single category for its rugged design and consistent output. Choose quality, choose onsemi.
Specifications
- Product Status: Obsolete
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 20 V
- Current - Continuous Drain (Id) @ 25°C: 3.5A (Ta)
- Drive Voltage (Max Rds On, Min Rds On): 1.8V, 4.5V
- Rds On (Max) @ Id, Vgs: 71mOhm @ 1.5A, 4.5V
- Vgs(th) (Max) @ Id: 1.3V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs: 2.8 nC @ 4.5 V
- Vgs (Max): ±12V
- Input Capacitance (Ciss) (Max) @ Vds: 260 pF @ 10 V
- FET Feature: -
- Power Dissipation (Max): 1W (Ta)
- Operating Temperature: 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: 3-CPH
- Package / Case: TO-236-3, SC-59, SOT-23-3
