NVMFS6H836NLWFT1G
onsemi
onsemi
MOSFET N-CH 80V 16A/77A 5DFN
$0.68
Available to order
Reference Price (USD)
1+
$0.68178
500+
$0.6749622
1000+
$0.6681444
1500+
$0.6613266
2000+
$0.6545088
2500+
$0.647691
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Upgrade your designs with the NVMFS6H836NLWFT1G by onsemi, a top-tier single MOSFET in the Discrete Semiconductor Products range. This component shines in high-power applications such as server farms, electric vehicle charging stations, and smart grid technology. With its low conduction losses and high reliability, the NVMFS6H836NLWFT1G is the ideal choice for engineers working with Transistors - FETs, MOSFETs - Single components.
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 80 V
- Current - Continuous Drain (Id) @ 25°C: 16A (Ta), 77A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 6.2mOhm @ 15A, 10V
- Vgs(th) (Max) @ Id: 2V @ 95µA
- Gate Charge (Qg) (Max) @ Vgs: 34 nC @ 10 V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 1950 pF @ 40 V
- FET Feature: -
- Power Dissipation (Max): 3.7W (Ta), 89W (Tc)
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: 5-DFN (5x6) (8-SOFL)
- Package / Case: 8-PowerTDFN, 5 Leads
