IKY75N120CS6XKSA1
Infineon Technologies
Infineon Technologies
IGBT TRENCH 1200V 150A TO247-4
$12.33
Available to order
Reference Price (USD)
1+
$20.22000
10+
$18.71600
240+
$16.05646
720+
$14.46051
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The IKY75N120CS6XKSA1 Single IGBT transistor by Infineon Technologies is a versatile component in the Discrete Semiconductor Products range. Designed for efficiency and durability, it features high voltage tolerance and minimal power dissipation. Ideal for use in automotive electronics, HVAC systems, and power tools, the IKY75N120CS6XKSA1 provides consistent performance in varied conditions. Rely on Infineon Technologies's innovation to power your next-generation devices with this high-quality IGBT.
Specifications
- Product Status: Active
- IGBT Type: Trench Field Stop
- Voltage - Collector Emitter Breakdown (Max): 1200 V
- Current - Collector (Ic) (Max): 150 A
- Current - Collector Pulsed (Icm): 300 A
- Vce(on) (Max) @ Vge, Ic: 2.15V @ 15V, 75A
- Power - Max: 880 W
- Switching Energy: 2.2mJ (on), 2.95mJ (off)
- Input Type: Standard
- Gate Charge: 530 nC
- Td (on/off) @ 25°C: 32ns/300ns
- Test Condition: 600V, 75A, 4Ohm, 15V
- Reverse Recovery Time (trr): 205 ns
- Operating Temperature: -40°C ~ 175°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-247-4
- Supplier Device Package: PG-TO247-4-2
