AFGY100T65SPD
onsemi
onsemi
IGBT - 650 V 100 A FS3 FOR EV TR
$10.44
Available to order
Reference Price (USD)
1+
$10.44000
500+
$10.3356
1000+
$10.2312
1500+
$10.1268
2000+
$10.0224
2500+
$9.918
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Optimize your power systems with the AFGY100T65SPD Single IGBT transistor from onsemi. This Discrete Semiconductor Product is engineered for precision and efficiency, offering superior thermal performance and low EMI characteristics. Ideal for applications like electric vehicle charging stations, renewable energy systems, and industrial automation, the AFGY100T65SPD delivers consistent and reliable operation. Trust onsemi's expertise in semiconductor technology to enhance your power management solutions with this high-quality IGBT.
Specifications
- Product Status: Active
- IGBT Type: Trench Field Stop
- Voltage - Collector Emitter Breakdown (Max): 650 V
- Current - Collector (Ic) (Max): 120 A
- Current - Collector Pulsed (Icm): 300 A
- Vce(on) (Max) @ Vge, Ic: 2.05V @ 15V, 100A
- Power - Max: 660 W
- Switching Energy: 5.1mJ (on), 2.7mJ (off)
- Input Type: Standard
- Gate Charge: 109 nC
- Td (on/off) @ 25°C: 36ns/78ns
- Test Condition: 400V, 100A, 5Ohm, 15V
- Reverse Recovery Time (trr): 105 ns
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-247-3
- Supplier Device Package: TO-247-3
