IPB80N06S2L09ATMA2
Infineon Technologies
Infineon Technologies
MOSFET N-CH 55V 80A TO263-3
$1.83
Available to order
Reference Price (USD)
1,000+
$0.80372
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The IPB80N06S2L09ATMA2 single MOSFET from Infineon Technologies is a game-changer in power electronics. As part of the Discrete Semiconductor Products family, it offers unparalleled efficiency in energy conversion and management. Key applications include uninterruptible power supplies (UPS), welding equipment, and industrial motor drives. With features like high temperature operation and ESD protection, the IPB80N06S2L09ATMA2 is a must-have in the Transistors - FETs, MOSFETs - Single category.
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 55 V
- Current - Continuous Drain (Id) @ 25°C: 80A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 8.2mOhm @ 52A, 10V
- Vgs(th) (Max) @ Id: 2V @ 125µA
- Gate Charge (Qg) (Max) @ Vgs: 105 nC @ 10 V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 2620 pF @ 25 V
- FET Feature: -
- Power Dissipation (Max): 190W (Tc)
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: PG-TO263-3-2
- Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
