STGP3HF60HD
STMicroelectronics
STMicroelectronics
IGBT BIPO 600V 3A TO220
$1.17
Available to order
Reference Price (USD)
1+
$0.99000
50+
$0.81980
100+
$0.67740
500+
$0.54502
1,000+
$0.44506
2,500+
$0.40758
5,000+
$0.38259
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Optimize your power systems with the STGP3HF60HD Single IGBT transistor from STMicroelectronics. This Discrete Semiconductor Product is engineered for precision and efficiency, offering superior thermal performance and low EMI characteristics. Ideal for applications like electric vehicle charging stations, renewable energy systems, and industrial automation, the STGP3HF60HD delivers consistent and reliable operation. Trust STMicroelectronics's expertise in semiconductor technology to enhance your power management solutions with this high-quality IGBT.
Specifications
- Product Status: Active
- IGBT Type: -
- Voltage - Collector Emitter Breakdown (Max): 600 V
- Current - Collector (Ic) (Max): 7.5 A
- Current - Collector Pulsed (Icm): 18 A
- Vce(on) (Max) @ Vge, Ic: 2.95V @ 15V, 1.5A
- Power - Max: 38 W
- Switching Energy: 19µJ (on), 12µJ (off)
- Input Type: Standard
- Gate Charge: 12 nC
- Td (on/off) @ 25°C: 11ns/60ns
- Test Condition: 400V, 1.5A, 100Ohm, 15V
- Reverse Recovery Time (trr): 85 ns
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220
