STGP7NC60HD
STMicroelectronics
STMicroelectronics
IGBT 600V 25A 80W TO220
$1.70
Available to order
Reference Price (USD)
1+
$1.71000
50+
$1.46380
100+
$1.26180
500+
$1.05430
1,000+
$0.89050
2,500+
$0.83590
5,000+
$0.82680
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Upgrade your power management systems with the STGP7NC60HD Single IGBT transistor from STMicroelectronics. This Discrete Semiconductor Product boasts high current density and excellent thermal conductivity, making it suitable for high-power applications. From railway systems to wind turbines, the STGP7NC60HD provides reliable and efficient operation. STMicroelectronics's advanced semiconductor technology guarantees a component that excels in performance and durability. Choose STGP7NC60HD for your critical power needs.
Specifications
- Product Status: Active
- IGBT Type: -
- Voltage - Collector Emitter Breakdown (Max): 600 V
- Current - Collector (Ic) (Max): 25 A
- Current - Collector Pulsed (Icm): 50 A
- Vce(on) (Max) @ Vge, Ic: 2.5V @ 15V, 7A
- Power - Max: 80 W
- Switching Energy: 95µJ (on), 115µJ (off)
- Input Type: Standard
- Gate Charge: 35 nC
- Td (on/off) @ 25°C: 18.5ns/72ns
- Test Condition: 390V, 7A, 10Ohm, 15V
- Reverse Recovery Time (trr): 37 ns
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220
