STGD6NC60HDT4
STMicroelectronics
STMicroelectronics
IGBT 600V 15A 56W DPAK
$1.48
Available to order
Reference Price (USD)
2,500+
$0.63910
5,000+
$0.61215
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Enhance your electronic projects with the STGD6NC60HDT4 Single IGBT transistor from STMicroelectronics. This Discrete Semiconductor Product offers exceptional performance with low switching losses and high current capacity. Suitable for applications such as medical equipment, aerospace systems, and consumer electronics, the STGD6NC60HDT4 ensures precision and reliability. STMicroelectronics's cutting-edge technology guarantees a component that meets the highest industry standards. Choose STGD6NC60HDT4 for efficient and durable power solutions.
Specifications
- Product Status: Active
- IGBT Type: -
- Voltage - Collector Emitter Breakdown (Max): 600 V
- Current - Collector (Ic) (Max): 15 A
- Current - Collector Pulsed (Icm): 21 A
- Vce(on) (Max) @ Vge, Ic: 2.5V @ 15V, 3A
- Power - Max: 56 W
- Switching Energy: 20µJ (on), 68µJ (off)
- Input Type: Standard
- Gate Charge: 13.6 nC
- Td (on/off) @ 25°C: 12ns/76ns
- Test Condition: 390V, 3A, 10Ohm, 15V
- Reverse Recovery Time (trr): 21 ns
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package: DPAK
