IXYH50N120C3
IXYS
IXYS
IGBT 1200V 100A 750W TO247AD
$12.52
Available to order
Reference Price (USD)
1+
$9.79000
10+
$8.81200
30+
$8.02867
120+
$7.24550
270+
$6.65804
510+
$6.07057
1,020+
$5.28727
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The IXYH50N120C3 by IXYS is a premium Single IGBT transistor designed for high-power applications. Part of the Discrete Semiconductor Products family, it features fast switching speeds and high input impedance, reducing power loss and improving efficiency. Commonly used in motor control, power supplies, and renewable energy inverters, this IGBT is built to withstand harsh environments. With IXYS's reputation for quality, the IXYH50N120C3 is a dependable choice for demanding electronic designs.
Specifications
- Product Status: Active
- IGBT Type: -
- Voltage - Collector Emitter Breakdown (Max): 1200 V
- Current - Collector (Ic) (Max): 100 A
- Current - Collector Pulsed (Icm): 240 A
- Vce(on) (Max) @ Vge, Ic: 3.5V @ 15V, 50A
- Power - Max: 750 W
- Switching Energy: 3mJ (on), 1mJ (off)
- Input Type: Standard
- Gate Charge: 142 nC
- Td (on/off) @ 25°C: 28ns/133ns
- Test Condition: 600V, 50A, 5Ohm, 15V
- Reverse Recovery Time (trr): -
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-247-3
- Supplier Device Package: TO-247 (IXYH)
