STGWA20M65DF2
STMicroelectronics
STMicroelectronics
IGBT TRENCH 650V 40A TO247
$2.08
Available to order
Reference Price (USD)
600+
$1.74300
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The STGWA20M65DF2 from STMicroelectronics is a high-performance Single IGBT transistor designed for robust and efficient power management in various applications. As part of the Discrete Semiconductor Products category, this IGBT offers low saturation voltage and fast switching capabilities, making it ideal for high-efficiency power conversion. Its advanced design ensures thermal stability and durability, even under demanding conditions. Common applications include motor drives, solar inverters, and industrial power supplies, where reliable and efficient switching is crucial. Choose STGWA20M65DF2 for superior performance in your next power electronics project.
Specifications
- Product Status: Active
- IGBT Type: Trench Field Stop
- Voltage - Collector Emitter Breakdown (Max): 650 V
- Current - Collector (Ic) (Max): 40 A
- Current - Collector Pulsed (Icm): 80 A
- Vce(on) (Max) @ Vge, Ic: 2V @ 15V, 20A
- Power - Max: 166 W
- Switching Energy: 140µJ (on), 560µJ (off)
- Input Type: Standard
- Gate Charge: 63 nC
- Td (on/off) @ 25°C: 26ns/108ns
- Test Condition: 400V, 20A, 12Ohm, 15V
- Reverse Recovery Time (trr): 166 ns
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-247-3
- Supplier Device Package: TO-247 Long Leads
Related Products
Infineon Technologies
IKD06N60R
Microchip Technology
APT75GN120LG
Infineon Technologies
IGZ50N65H5XKSA1
Renesas Electronics America Inc
RJH60M1DPE-00#J3
STMicroelectronics
STGWA30HP65FB
Rohm Semiconductor
RGT8NS65DGC9
Fairchild Semiconductor
FGPF7N60RUFDTU
IXYS
IXGH24N170A
Infineon Technologies
IKW40N65ET7XKSA1
