STGWT40HP65FB
STMicroelectronics
STMicroelectronics
TRENCH GATE FIELD-STOP IGBT, HB
$3.29
Available to order
Reference Price (USD)
1+
$2.63000
10+
$2.36500
100+
$1.90100
600+
$1.56188
1,200+
$1.29413
3,000+
$1.20488
5,400+
$1.19000
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the STGWT40HP65FB Single IGBT transistor by STMicroelectronics, a standout in the Discrete Semiconductor Products lineup. This component excels in high-voltage and high-current applications, featuring low conduction losses and excellent switching performance. Perfect for use in welding equipment, UPS systems, and induction heating, the STGWT40HP65FB ensures reliability and efficiency. Its rugged construction and advanced technology make it a top choice for engineers seeking durable and high-performing IGBTs. Upgrade your designs with the STGWT40HP65FB for unmatched power control.
Specifications
- Product Status: Active
- IGBT Type: Trench Field Stop
- Voltage - Collector Emitter Breakdown (Max): 650 V
- Current - Collector (Ic) (Max): 80 A
- Current - Collector Pulsed (Icm): 160 A
- Vce(on) (Max) @ Vge, Ic: 2V @ 15V, 40A
- Power - Max: 283 W
- Switching Energy: 363µJ (off)
- Input Type: Standard
- Gate Charge: 210 nC
- Td (on/off) @ 25°C: -/142ns
- Test Condition: 400V, 40A, 5Ohm, 15V
- Reverse Recovery Time (trr): 140 ns
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-3P-3, SC-65-3
- Supplier Device Package: TO-3P
